Walk into any hardware store and ask for the “thing under the sink that holds water” and you will be redirected to three different aisles. Knowing the actual bathroom sink parts names turns a confusing trip into a five-minute checkout, and it makes plumbing repairs far less intimidating. There are only about fifteen named components in a standard residential sink. Learn them once and you can troubleshoot leaks, slow drains, and wobbly faucets without calling anyone.
Part of our Bathroom Remodeling & Flooring guide — explore the full guide →
- The Faucet Assembly: Above the Counter
- Under the Sink: Supply Side
- The Drain Assembly: Above the P-Trap
- The P-Trap and Drain Arm
- Vent and DWV Lines: Behind the Wall
- Pop-Up Mechanism Step-by-Step
- Tools You Will Use Most Often
- Common Failure Points and Repair Costs
- When to Call a Plumber
- Putting the Vocabulary to Work
The Faucet Assembly: Above the Counter
The faucet itself breaks into the spout, handles, and the trim plates. The decorative plate at the base that covers the mounting holes is the escutcheon, sometimes called the deck plate. Cartridges or ceramic discs sit inside each handle and control flow; brands like Moen use a 1225 cartridge, Delta uses an RP series, and Kohler runs ceramic discs in many of their lineup.
Under each handle you will find a set screw, often hidden behind a hot-cold index button that pops off with a pocketknife. Aerators screw into the tip of the spout and unscrew counterclockwise. They cost $5 to $12 and account for nearly every “low water pressure” call.
Under the Sink: Supply Side
The flexible braided lines running from the wall up to the faucet are supply lines. Standard lengths are 12, 16, and 20 inches with a 3/8-inch compression end at the valve and a 1/2-inch IPS connection at the faucet. Stainless braided lines from Fluidmaster or BrassCraft run $8 to $16 each and should be replaced every ten years.
Where the supply line meets the wall, you have the shutoff valve, also called an angle stop. Quarter-turn ball valves are the modern standard at $12 to $22 and are vastly better than the old multi-turn compression stops that seize after five years of no use. Behind the wall, the valve threads onto the stub-out, a short pipe protruding from the framing.
The Drain Assembly: Above the P-Trap
This is where most homeowners get lost. From the basin down, the parts are:
- Pop-up flange: the chrome ring you see in the bottom of the sink
- Sink stopper: the lift-up plug that holds water
- Pop-up assembly: the mechanism with the horizontal pivot rod
- Tailpiece: the straight chrome or PVC pipe directly below the sink
- Slip nuts and washers: the white plastic or chrome nuts that join sections
- Lift rod and clevis strap: the vertical pull rod and the perforated strip that connects it to the pivot rod
A complete pop-up kit from Plumb Pak or Danco runs $18 to $35 and includes every piece between the sink and the trap.
The P-Trap and Drain Arm
The U-shaped bend below the tailpiece is the P-trap, named for its sideways P shape. It holds about a cup of water to block sewer gas. The horizontal piece running into the wall is the trap arm, and where it disappears into the wall is the trap adapter, hidden behind the chrome escutcheon. Replacements are PVC for $6 to $12 or chrome-plated brass for $25 to $45. The IPC code requires a trap on every fixture and a maximum tailpiece length of 24 inches before the trap.
Vent and DWV Lines: Behind the Wall
Beyond the trap adapter, the drain ties into the building’s drain-waste-vent system. The vent stack rises through the wall and out the roof, balancing pressure so the trap does not siphon dry. You will not see these parts during normal maintenance, but a gurgling sink almost always means a partial vent blockage, not a clog at the trap.
Pop-Up Mechanism Step-by-Step
The pop-up is the single most-repaired part because hair and toothpaste film bind it monthly. To service it: pull the lift rod up, unscrew the retainer nut on the back of the tailpiece, and slide out the horizontal pivot rod. The stopper lifts straight out. Clean both with vinegar and a brush, replace the rubber O-ring on the pivot rod if it is cracked ($2 from any plumbing aisle), and reassemble. Adjust the clevis strap clip so the stopper seals when the rod is up.
Tools You Will Use Most Often
- Channel-lock pliers, 10-inch (Knipex Cobra or Channellock 430)
- Basin wrench for the nuts above the faucet body
- Adjustable crescent wrench, 8-inch
- Phillips and flat-head screwdrivers
- Plumber’s putty (Oatey) or silicone sealant (GE 100)
- Teflon tape, white for water and yellow for gas
- A small flashlight or headlamp
Total tool investment under $80, and you will use them on dozens of repairs over a decade.
Common Failure Points and Repair Costs
Aerators clog from sediment, $6 fix. Supply lines burst at the crimp, $14 each. Shutoff valves stick, $22 plus 20 minutes. Pop-up assemblies leak at the gasket, $25 kit. P-traps sag and leak at the slip nuts, $10 in washers. The faucet cartridge drips, $25 to $90 depending on brand. Cumulative parts to refurbish an entire sink: under $200.
When to Call a Plumber
If the shutoff valve will not close and the leak is upstream of it, you have a stub-out or supply line issue inside the wall. That is plumber territory. Same for any leak at the trap adapter that does not stop after replacing the slip washers, since the adapter may have separated inside the wall cavity. A licensed plumber bills $95 to $180 per hour in most metros, but a sink rebuild rarely exceeds two hours of labor.
Putting the Vocabulary to Work
The next time the basin will not hold water, you know to inspect the pop-up assembly, not the trap. The next time pressure drops, you start at the aerator, not the valve. Knowing bathroom sink parts names is the difference between a five-dollar fix and a hundred-dollar service call.
