Metal Shed Roof: How to Install Panels on a Storage Shed

A shed roof that drips on your tools every cold morning is usually not leaking at all. It is condensation forming under bare metal. A properly built metal shed roof solves that problem and lasts for decades, as long as you get a few details right: solid support under the panels, the correct screw pattern, foam closure strips at the eaves and ridge, and some way to manage moisture underneath. On a typical storage shed you can install panels over purlins or over plywood decking, overhang the eaves by about 1 to 2 inches, and fasten with gasketed screws through the flat or the rib depending on the panel profile.

Part of our Roofing guide — explore the full guide →

Shed-scale work is much simpler than roofing a house, but it rewards careful layout. Here is the process from framing to final trim, with the decisions that matter most for a small building.

Planning a Metal Shed Roof

Start with the roof’s slope, size and the panel style you want. Exposed-fastener panels, such as corrugated or ribbed profiles, are the usual choice for sheds because they are affordable, widely stocked and easy to install with basic tools. Standing seam panels hide their fasteners and look cleaner, but they cost more and require more precise work.

Check the slope. Most exposed-fastener panels need at least a 3:12 pitch, meaning 3 inches of rise for every 12 inches of run, to shed water reliably. Some profiles allow lower pitches with sealant and lap tape, so read the panel maker’s guidance. A lean-to shed with a very shallow slope may need a different panel or extra sealing at the laps.

Measure the roof from eave to ridge (or eave to high wall on a single-slope shed) and add your overhang. Panels are commonly sold in lengths cut to order, so you can order them to length and avoid field cuts.

Purlins vs Solid Decking

This is the main structural choice, and both work on a shed.

Purlins

Purlins are horizontal boards, usually 2x4s laid flat or on edge, fastened across the rafters. Panels screw directly into them. Spacing typically runs 24 inches on center for most residential panels, though some lighter gauges or high snow areas need closer spacing. Purlins are cheaper and lighter than decking and let air circulate under the panels. The downside is no solid layer for an underlayment, which makes condensation harder to control.

Solid decking

Plywood or OSB sheathing, usually 1/2 inch or thicker, gives you a continuous surface. You can lay a synthetic underlayment over it, which catches condensation and adds a second line of defense against leaks. Decking also stiffens the roof and makes walking during installation safer. It costs more and adds weight, but for a shed that stores tools, a workshop or anything sensitive to moisture, decking with underlayment is the better choice.

A hybrid is common too: purlins installed over solid decking. That raises the panels slightly for airflow while keeping the underlayment layer.

Tools and Materials

• Metal roof panels, such as corrugated metal roof panels in 26 or 29 gauge
• Gasketed roofing screws, often 1 inch to 1.5 inches long, matched to the panel color
• Foam closure strips shaped to your panel profile, for eaves and ridge
• Drip edge, eave trim, rake or gable trim and ridge cap
• Synthetic underlayment if installing over decking
• Butyl sealant tape for laps on low slopes
• Drill driver with a magnetic hex bit
• Metal snips, and a nibbler or circular saw with a metal-cutting blade for longer cuts
• Chalk line, tape measure, speed square
• Gloves, safety glasses, hearing protection

Step-by-Step Panel Installation

1. Prep the frame. Make sure rafters are secure and in plane. Install purlins or sheathing, checking that the roof is square by measuring the diagonals.
2. Install underlayment and drip edge. On decked roofs, put drip edge along the eaves first, then roll out underlayment from the bottom up, overlapping per the label. Rake trim can go on now or after the panels, depending on the trim style.
3. Set eave closures. Lay the foam closure strip along the eave, positioned where the panel bottom will sit. It blocks wind-driven rain, insects and birds from entering under the ribs.
4. Square the first panel. Start at the end opposite the prevailing wind so laps face away from it. Align the first panel square to the eave, letting it overhang about 1 to 2 inches. A crooked first panel will make every panel after it crooked.
5. Fasten in the right pattern. Drive screws in straight lines over each purlin or along chalked lines on decking. Follow the panel maker’s pattern; many corrugated profiles call for screws every second or third corrugation at each purlin, with more at the eaves and ridge.
6. Overlap the next panel. Lap each panel over the previous one by the profile’s specified amount, often one full rib or corrugation. On low slopes, run butyl tape along the lap first.
7. Cut the last panel. Measure, mark and cut the final panel to width, keeping the cut edge at the rake where trim will cover it.
8. Install ridge closures and cap. Place closure strips at the top of the panels, then set the ridge cap and fasten it through the closures into the high ribs.
9. Add rake trim. Fasten gable trim along the sides to cover panel edges and lock everything down.
10. Sweep off metal shavings. Drill filings left on the roof will rust and stain the finish within days.

Screws: Flat vs Rib and How Tight

Screw placement is debated. Many panel makers specify fastening through the flat area next to the rib, where the panel sits tight against the purlin and the screw can compress the washer evenly. Some installers prefer the high rib to keep the fastener above water flow, but that requires longer screws and careful seating so the rib does not crush. Follow the instructions for your specific profile.

Tightness matters more than most people realize. Drive each screw until the rubber washer just compresses and bulges slightly at the edges. Underdriven screws leak. Overdriven screws split the washer or dimple the metal, and they leak too. Use a drill with a clutch setting to keep them consistent.

Overhangs and Edge Details

At the eaves, an overhang of 1 to 2 inches past the drip edge directs water into a gutter or away from the wall. Too much overhang lets wind lift the panel; too little lets water wick back under. At the rakes, the panel should end flush or just inside the trim. If you plan to add gutters later, check that the overhang lines up with the gutter’s back edge.

Controlling Condensation

Metal cools quickly at night. When warm, humid air inside the shed touches the cold underside of the panel, water condenses and drips. On a storage shed this can rust tools, mildew boxes and stain the floor.

• Use underlayment over decking: The simplest fix. Condensation forms on the panel but drains down the underlayment rather than dripping inside.
• Choose panels with a condensation backing: Some panels come with a felt-like fabric bonded to the underside that absorbs moisture and releases it slowly.
• Ventilate: Gable vents, ridge vents or soffit vents keep inside air closer to outside conditions.
• Keep moisture sources out: Avoid storing wet equipment and make sure the floor is sealed or raised off damp ground.

Over open purlins, a reflective radiant barrier or anti-condensation membrane draped over the purlins before the panels can help considerably.

Ladder and Roof Safety

Even a low shed can cause a serious fall. Set your extension ladder on firm, level ground at a 4 to 1 angle, extend it at least 3 feet above the roof edge, and keep three points of contact. Never stand on bare metal panels, which are slippery even when dry and can buckle between supports. Work from a ladder or a plank laid across the purlins, wear soft-soled shoes, and skip work in wind, rain or frost. Handle panels with cut-resistant gloves, since edges are razor sharp, and get a helper to carry long sheets, which catch wind like a sail. A shed attached to a house or anything taller than a single story is a job for a roofing pro.

Troubleshooting Common Problems

• Leaks at screws: Washers under- or overdriven. Replace with an oversized gasketed screw.
• Leaks at laps: Lap too small or facing into wind. Add butyl tape and stitch screws along the lap.
• Drips inside on cold mornings: Condensation, not a leak. Add ventilation or a backing membrane.
• Wavy panels: Purlins out of plane. Shim low purlins before fastening.
• Rust spots: Leftover metal shavings. Sweep them off, and touch up with matching paint.

Cost of a Metal Shed Roof

Material costs vary widely with panel gauge, profile and coating. For a typical 10 by 12 foot shed, panels, screws, closures and trim often land in the low to mid hundreds of dollars, and decking and underlayment add more. A professional install on a small shed may run several hundred to over a thousand dollars depending on region and complexity. Metal often outlasts asphalt shingles by decades, which makes the upfront cost easier to justify.

When to Call a Pro

Hire a roofer if your shed is larger than a simple single-story outbuilding, has a complex roof shape or skylights, or sits in a high wind or heavy snow area where fastener schedules and purlin spacing need engineering. Check with your local building department and HOA, since some sheds require permits once they exceed a certain size.
