Curbless Shower Installation: Recessing, Slope and Waterproofing

A curbless shower looks simple: the bathroom floor just continues into the shower with no step. Behind that clean look is the most demanding part of any bathroom remodel. The shower floor still has to slope to a drain, and since there is no curb to hold water back, the slope has to start lower than the level of the bathroom floor. That means curbless shower installation almost always involves lowering part of the subfloor or slab, then building a fully waterproofed, carefully pitched floor that keeps every drop where it belongs.

Part of our Bathroom Remodeling & Flooring guide — explore the full guide →

The short version of the sequence: plan the drain and the size of the wet zone, recess the floor framing or cut the slab, install the drain, build the slope, waterproof the entire shower area plus a margin beyond it, flood test, and then tile. Skipping or rushing any of those steps is how zero threshold showers end up soaking the hallway.

Much of the work involves structure, plumbing and waterproofing, so many homeowners hire a contractor for the rough stages and handle only the finish work. Knowing the sequence still helps you ask the right questions and spot shortcuts.

Planning a Curbless Shower Installation

Good outcomes are decided before any demolition. Settle these points first:

• Drain type: a linear (trench) drain lets the floor slope in one direction, usually toward the back wall, which makes the entry transition much easier. A center point drain needs a four-way slope and a deeper recess.
• Wet zone size: the sloped area should extend at least a couple of feet beyond the shower head spray. Many designers plan the full shower footprint plus the entry area as the waterproofed zone.
• Slope depth: the standard minimum slope is 1/4 inch per foot. A 5 foot run to a linear drain needs about 1-1/4 inches of drop, plus the thickness of the drain body, mortar or foam tray, membrane and tile.
• Glass and containment: a fixed glass panel, careful head placement and a linear drain at the entry or back wall all reduce splash. Some designs add a second drain at the threshold.
• Accessibility goals: a zero entry shower installation designed for wheelchair use needs more clear floor space, blocking for grab bars and a handheld shower.
• Permits: structural changes, new drains and relocated plumbing typically require permits and inspections. Check with your local building department.

Option 1: Recessing a Wood-Framed Floor

In homes with joists, the shower area must drop enough to fit the slope and materials while the bathroom floor stays at its finished height. Common approaches:

Lowering the subfloor between joists

Remove the subfloor in the shower area and install new subfloor on cleats (ledgers) fastened to the sides of the joists, set lower than the joist tops. This gives roughly 3/4 to 1-1/2 inches of drop without cutting the joists. It works only if the joists are deep enough and the span allows it.

Notching or sistering joists

Larger recesses sometimes require cutting into joists, which weakens them. Any notching must be engineered: joists are typically sistered with new full-length lumber, headers may be added, and the plan should be reviewed by a structural engineer or the building inspector. Never notch joists without that review, especially at mid-span.

Building up the surrounding floor

Instead of lowering the shower, some remodels raise the remaining bathroom floor with an extra layer of plywood or a thicker tile bed. This avoids cutting framing but creates a transition at the bathroom door that you will need to manage.

Whichever method you use, the joists under a tile shower must meet stiffness requirements for tile (commonly at least L/360 for ceramic and porcelain, stiffer for natural stone). Bouncy floors crack grout and tear membranes.

Option 2: Cutting a Concrete Slab

On slab-on-grade homes, the slab is cut and excavated in the shower area so a new, lower bed can be poured. The usual steps:

1. Locate post-tension cables before any cutting. Post-tensioned slabs are dangerous to cut and require a specialist and engineering approval.
2. Saw-cut the outline and break out the concrete, often 2 to 4 inches deep or more depending on the drain.
3. Reroute or replace the drain line below the slab to meet the new drain location, with proper fall and a trap.
4. Pour a new recessed slab or mortar bed, typically with a vapor barrier and doweling into the existing slab.

Concrete cutting creates crystalline silica dust. Use wet cutting, wear a properly fitted N95 or P100 respirator, and clean up with a HEPA vacuum rather than sweeping.

Tools and Materials

• Linear or point drain designed for bonded sheet or liquid membranes
• Pre-sloped foam shower tray, a curbless shower pan kit, or materials for a sand and cement mortar bed
• Bonded waterproofing membrane (sheet or liquid) with matching seam tape, corners and drain collar
• Cement board or foam backer board for walls
• Long level, slope gauge or digital level, and a straightedge
• Thinset mortar suited to the membrane, plus tile and grout
• Respirator, eye protection, gloves and a HEPA vacuum for demo and cutting

Pre-sloped foam trays and curbless pan kits cut down on the skill needed to float a perfect mortar slope and are widely used for DIY-friendly installs. Mortar beds remain common with professionals and offer more flexibility for odd shapes.

Step-by-Step Installation Sequence

1. Demolish and inspect. Remove old finishes to the framing or slab. Check for rot, past leaks and mold. Fix the source of any moisture first. Mold growth larger than about 10 square feet should be handled by a remediation professional.
2. Create the recess. Lower the subfloor or cut the slab as planned, with structural approval where framing is altered.
3. Set the drain. Install the drain body at the correct height so the finished tile will sit flush with the drain grate. A licensed plumber should handle new drain lines, traps and venting.
4. Build the slope. Install the foam tray or float the mortar bed at a minimum 1/4 inch per foot toward the drain, with no low spots. Check with a level across many directions; a puddle-prone floor is very hard to fix later.
5. Prepare the walls. Install backer board, with blocking already in place for grab bars, niches and glass panels.
6. Waterproof everything. Apply the bonded membrane over the entire sloped floor, up the walls (to the ceiling in steam showers, at least higher than the shower head otherwise), and out past the shower onto the bathroom floor. Many installers waterproof the whole bathroom floor. Seal corners, seams, drain connections and every pipe and valve penetration with the system’s preformed pieces.
7. Flood test. Plug the drain and fill the shower floor with an inch or so of water for at least 24 hours (or as the membrane maker specifies). Mark the waterline and check the ceiling or crawlspace underneath for leaks. Many inspectors require this.
8. Tile the floor. Use smaller tiles (2 inch mosaics or similar) for a point drain so the tile can follow the four-way slope. A linear drain allows large-format tile because the slope is a single plane.
9. Tile walls and transitions. Make the bathroom-to-shower transition flush with no lip. Slope the tile edge where the shower floor meets the bathroom floor so water does not sit at the line.
10. Install glass and fixtures. Fixed panels or doors need solid anchoring into backing. Let grout and sealants cure fully before use.

Water Containment: Keeping the Bathroom Dry

Without a curb, these details carry the load:

• Drain placement: a linear drain at the entry catches water before it reaches the bathroom floor; at the back wall it pulls water away from the entry.
• Shower head orientation: aim the main spray away from the opening.
• Glass panel length: a fixed panel covering at least half of the shower opening controls most splash.
• Extended waterproofing: membrane well past the wet zone protects the subfloor from overspray and mopping.
• Floor slope continuity: the bathroom floor should not slope toward the hallway. A slight pitch toward the shower helps.

Troubleshooting Common Problems

• Puddles on the shower floor: slope is too shallow or the bed has a low spot. Small issues can sometimes be fixed by regrouting larger tiles into smaller ones, but true slope problems need the floor rebuilt.
• Water reaching the bathroom floor: the drain is too far from the entry, the slope starts too late, or there is no splash panel. A secondary threshold drain or a longer glass panel often helps.
• Cracked grout near the entry: floor deflection or a missing movement joint. Check framing stiffness and add a soft joint at the change of plane.
• Musty smell or stains below: a membrane failure, often at a pipe penetration or drain connection. Stop using the shower and investigate.
• Tile lippage at the drain: the drain was set at the wrong height. Many linear drains have adjustable grates; otherwise the drain must be reset.

Curbless Shower Installation Costs

Costs vary widely with structure and finishes. A curbless conversion with professional labor commonly ranges from several thousand dollars on the low end for a simple wood-framed recess with a foam tray, to well over ten thousand dollars when slab cutting, plumbing relocation, structural work and premium tile or glass are involved. Engineering review, permits and inspections add to the total. DIY savings are mainly in demolition, tile and finish work; structural, plumbing and waterproofing errors are the expensive ones to redo.

When to Call a Licensed Professional

Bring in licensed professionals for these parts of the project:

• Structural changes: any joist cutting, sistering or slab removal should be reviewed by a structural engineer or building official, and post-tension slabs require specialist handling.
• Plumbing: new or relocated drains, traps, venting and supply lines should be done by a licensed plumber under permit.
• Electrical: new lighting, heated floors or exhaust fans need a licensed electrician; bathroom outlets must be GFCI protected.
• Waterproofing: if you are not confident with membrane systems, hire a tile installer experienced in curbless builds. Ask about their flood testing.

Always pull permits where required, and keep inspection records for resale.
