Pocket Door Track Kit: Complete Guide for Homeowners

A swinging door steals up to 10 square feet of usable floor space, which is exactly why a pocket door track kit is one of the best space-saving upgrades in a tight bathroom, closet, or laundry room. The door slides sideways into a hollow wall cavity instead of arcing into the room, and the whole system rides on a hidden overhead track. The kit is the heart of it all, and choosing the right one, with the right weight rating and rough opening, makes the difference between smooth sliding and a door that jumps its track. Here is how to get it right.

Part of our Windows & Doors guide — explore the full guide →

What Comes in a Pocket Door Track Kit

A typical kit is a frame-and-hardware package, not the door itself. Inside you will find the overhead track, split jamb studs that create the pocket cavity, roller hangers or trolleys that carry the door, floor guides, and mounting hardware. Premium kits like Johnson Hardware’s 1500 series or the Cavity Sliders system add adjustable soft-close mechanisms and heavier-rated rollers. Budget kits cover the basics for a light hollow-core door.

Match the Kit to Your Door Weight

The single most important spec is the weight rating. A kit rated for a 75-pound hollow-core door will fail fast under a solid-core or glass door.

• Standard kits: Handle 75 to 125 pounds, fine for typical hollow-core interior doors.
• Heavy-duty kits: Rated 150 to 400 pounds for solid-core, solid-wood, or glass doors.
• Commercial or barn-style: Support 400-plus pounds with ball-bearing trolleys.

Weigh or estimate your door before buying. A solid-core 32-inch door can hit 90 to 110 pounds, so size the kit with headroom above the door’s actual weight.

Sizing the Rough Opening

Pocket doors need a rough opening roughly double the door width, because the door has to fully disappear into the wall. For a 32-inch door, plan a rough opening around 66 inches wide and about 84.5 inches tall for standard 80-inch doors. Always follow the specific kit’s rough-opening chart, since the numbers vary slightly by manufacturer. The pocket wall must also be non-load-bearing, or you will need a header and an engineering review before cutting into it.

Choosing Between Kit Styles

There are two broad families. A full frame kit includes the split studs and header to build the entire pocket, ideal for new construction or a wall you are opening up anyway. A track-only or converging kit suits situations where the framing already exists or you are retrofitting. For most remodels, the complete frame kit is worth it because the pre-engineered split studs guarantee the pocket is straight and the door will not rub.

Tools and Materials You’ll Need

Beyond the kit, gather a level, a stud finder, a reciprocating saw for demo, a drill, shims, and construction screws. You will also need new drywall to skin the pocket wall and finish materials, jamb trim, and casing. If you are relocating the wall’s electrical, that has to be moved out of the pocket area entirely, since you cannot run wiring or plumbing through a pocket cavity where the door slides.

Step-by-Step Installation Overview

1. Remove the existing wall covering back to the studs across the full rough opening width.
2. Frame or confirm the rough opening to the kit’s specified dimensions, level and plumb.
3. Mount the overhead track to the header, checking it is dead level so the door rolls freely.
4. Install the split jamb studs that form the pocket, spacing them per the instructions.
5. Hang the door on its roller trolleys, then adjust the height so the door clears the floor evenly.
6. Set the floor guide, install the pocket-door jambs, then drywall and finish the wall.

Getting a Smooth Glide

The reason cheap pocket doors stick is almost always an out-of-level track or an out-of-plumb pocket. Take extra time leveling the header track; even a slight tilt makes the door drift open or closed on its own. Most quality trolleys have vertical adjustment screws, so you can fine-tune the door’s height and reveal after hanging. Add a soft-close mechanism if your kit supports it to stop the jarring slam a heavy door can make.

Avoid These Common Mistakes

Do not run electrical or plumbing through the pocket wall, since a stray screw during finishing can pierce a wire or pipe hidden where the door hides. Never skimp on the weight rating to save a few dollars. Do not drywall the pocket with screws long enough to protrude into the cavity, or the door will scrape them. And test the door glide thoroughly before you close up the wall, because fixing a problem afterward means tearing the drywall back out.

Cost and Payoff

A quality pocket door track kit runs $60 to $250 depending on the weight rating and features, with the door, trim, and drywall adding another $150 to $400 in materials. Hiring a carpenter for the full job typically lands between $800 and $2,500. The payoff is permanent: usable floor space, a cleaner room layout, and a design detail that reads as thoughtful and custom in any home.

Retrofitting Into an Existing Wall

Adding a pocket door to a finished wall is the harder path, but it is doable. You will open the wall, confirm it is non-load-bearing, and reroute any electrical or plumbing that lives in the pocket zone. Because you are working within existing framing, measure carefully to be sure there is room for the full pocket beside the opening; a light switch, a return wall, or a window can block the space the door needs to slide into. When a true pocket is not feasible, a surface-mounted barn-door slider is a simpler alternative that skips the wall cavity entirely.

Final Word

A pocket door track kit turns wasted swing space into open floor, but only if you match the kit to your door’s weight, size the rough opening correctly, and obsess over a level track. Choose a complete frame kit for the straightest pocket, take your time on the leveling, and test the glide before you finish. Do that and you will enjoy a smooth, silent sliding door for decades.
