Vertical shiplap has quietly replaced subway tile as the go-to backsplash for modern farmhouse and coastal kitchens, and for good reason. A vertical shiplap backsplash stretches the ceiling height visually, costs roughly 60 percent less than mid-grade tile, and installs in a weekend with basic tools. The trick is using the right shiplap product, sealing it correctly behind a working kitchen, and choosing trim details that frame the panels for a finished look. I have installed dozens of these and the formula is repeatable.
Part of our Kitchen Remodeling guide — explore the full guide →
- Why Vertical Beats Horizontal Behind Counters
- Best Shiplap Materials for Kitchens
- Calculate Boards and Trim You Need
- Wall Prep and Layout
- Installation Steps That Save Time
- Caulk, Prime, and Paint for a Sealed Surface
- Color Combinations That Sell Houses
- Sealing Behind a Stove or Sink
- Total Project Cost and Timeline
Why Vertical Beats Horizontal Behind Counters
Horizontal shiplap is the classic Joanna Gaines look, but in a kitchen the horizontal seams catch every splash of grease and pasta water. Vertical orientation forces water and grease downward into the shadow line at the countertop, where a bead of silicone catches it. The eye also reads vertical lines as taller, which makes 8 foot ceilings feel closer to 9 foot.
Vertical shiplap also blends beautifully with vertical Shaker cabinet doors and tall pantry pulls, creating a cohesive visual rhythm that horizontal shiplap fights against. If you have a beadboard ceiling, vertical shiplap on the wall plays off it perfectly.
Best Shiplap Materials for Kitchens
Not every shiplap is kitchen-safe. Pine shiplap from a lumberyard absorbs water and warps. Use moisture-resistant options instead.
- UFP-Edge Shiplap MDF, $24 per 8 ft board, primed and ready to paint
- Allura fiber cement shiplap, $3.20 per sq ft, completely waterproof
- Boral TruExterior poly-ash shiplap, $4.10 per linear foot, dimensionally stable
- PVC shiplap from Royal Building Products, $3.80 per linear foot, zero water absorption
- Solid pine shiplap with two coats of marine varnish, $1.80 per linear foot, budget option
For a kitchen behind a sink or stove, I always recommend PVC or fiber cement. The 30 percent material cost premium pays back the first time someone leaves a wet sponge against the wall overnight.
Calculate Boards and Trim You Need
Measure the wall height from countertop to bottom of upper cabinets, usually 18 inches. A standard 4 inch face shiplap board covers 3.5 inches when installed. For a 12 foot run of countertop, you need 12 boards 18 inches long, or 6 boards 8 feet long ripped in half.
Add 1×2 outside corner trim, base shoe to close the gap at the countertop, and a small crown or simple flat band where the shiplap meets the underside of upper cabinets. Budget about $180 for materials on a 50 sq ft run including caulk and paint.
Wall Prep and Layout
Remove the outlet and switch covers, then pull each outlet 3/4 inch out of the box with longer 6-32 screws so it sits flush with the new shiplap surface. Box extenders from Carlon at $1.20 each preserve electrical code clearance.
Snap a vertical chalk line dead center of the wall using a 4 foot level. Work outward from center so the partial boards at each end are symmetric. Asymmetric end cuts make the install look amateur even when everything else is dialed in.
Installation Steps That Save Time
The cleanest install uses construction adhesive and finish nails, which means no visible screws and a tighter result than nails alone.
- Apply a zig-zag bead of Loctite PL Premium adhesive at $9 per tube on the back of each board.
- Press the board against the wall starting at center, lining up to the chalk line.
- Drive 2 inch 18-gauge brad nails through the tongue of each board at studs or every 16 inches.
- Engage the next board’s groove and tap home with a tapping block to avoid damaging the edge.
- Check plumb every third board with a 4 foot level. Adjust with a tapping block if needed.
Around outlets, mark the cutouts with a pencil before installation and use an oscillating multi-tool like the Fein Multimaster at $189 to make clean precise cuts.
Caulk, Prime, and Paint for a Sealed Surface
This is where many DIYers stop too early. Pre-primed MDF or PVC shiplap still needs caulk in every inside corner, around the perimeter, and at the countertop seam. Use a paintable siliconized acrylic like DAP Alex Plus at $4.50 per tube, smoothed with a wet finger in one continuous motion.
Spot-prime any exposed end cuts with a stain-blocking primer like Zinsser BIN at $26 per quart. Topcoat with two coats of Sherwin Williams Emerald Urethane Trim Enamel at $90 per gallon, which is the most durable paint for a kitchen environment. Allow 24 hours between coats.
Color Combinations That Sell Houses
White vertical shiplap behind navy or sage green cabinets is the most-photographed combination on Pinterest right now. Other tested pairings.
- Pure White SW 7005 shiplap with Hale Navy HC-154 cabinets
- Alabaster SW 7008 shiplap with Evergreen Fog SW 9130 cabinets
- Drift of Mist SW 9166 shiplap with white Shaker cabinets and oiled bronze hardware
- Iron Ore SW 7069 shiplap with white cabinets and brass pulls, dramatic and bold
Always test colors against your actual countertop and floor before committing. Lighting in a kitchen shifts every paint sample noticeably between morning and evening.
Sealing Behind a Stove or Sink
The 12 inches of shiplap directly behind a cooktop or sink takes the most abuse. Apply a third coat of Emerald Urethane in this zone for extra durability. Some installers add a clear epoxy topcoat from MAS Epoxies at $35 per quart for restaurant-grade washability.
Run a generous silicone bead at the countertop seam where splashes pool. Re-caulk this seam every 18 months because cabinet movement and temperature swings break the bond over time. Done right, a vertical shiplap backsplash holds up for 10 to 15 years in a hardworking family kitchen.
Total Project Cost and Timeline
A 50 sq ft vertical shiplap backsplash in PVC with paint and trim runs $380 to $620 in materials. For comparison, a comparable handmade subway tile job lands around $1,400 to $2,100 installed. DIY labor is about 12 to 16 hours over a long weekend, including prep and paint.
If you hire it out, expect a finish carpenter to charge $14 to $22 per sq ft installed including paint, which is still well below the $35 to $55 per sq ft for natural stone or zellige tile backsplash. The result reads custom and high-end on listing photos without the price tag of premium materials.
