Wire Color Chart: Complete Guide for Homeowners

Open any junction box in your house and you are looking at a coded language. A wire color chart tells you what each insulator color signals — which wires are hot, which are neutral, which carry ground, and which are switched legs waiting to power a load. Getting the colors right is not just convention; it is the difference between a safe circuit and a shock, a fire, or a code violation that tanks your home inspection.

The Basic US Residential Color Code

The National Electrical Code defines color conventions that every US residential electrician follows. At a 120/240V single-phase residential level, the standard colors are:

• Black — Hot (line voltage)
• Red — Hot (second leg of 240V, or switched hot in travelers)
• White — Neutral
• Bare copper or green — Equipment ground
• Blue, yellow, orange — Hot, used in multi-circuit or 3-phase contexts

For the 95% of residential wiring you will encounter, the first four colors cover everything you need to know.

The Black Wire: Hot Power

Black is always a hot, ungrounded conductor carrying line voltage back to the load. In a typical 120V branch circuit, black runs from the breaker to the first device and continues through the circuit. Touching a live black wire produces the same shock as touching the hot terminal of a live outlet.

Every black wire should be treated as energized until proven otherwise with a non-contact voltage tester. Even in a circuit you believe is off, verify before you grip.

The Red Wire: Second Hot or Traveler

Red has two common residential uses. In 240V circuits — electric dryers, ranges, water heaters, baseboard heaters — red is the second hot leg, paired with black to deliver 240V across the two phases. In three-way and four-way switch circuits, red is typically the traveler conductor running between switch pairs.

If you see red in a standard 120V outlet box, it is almost always a switched hot or a traveler, not a second phase. Context matters — trace the run before assuming.

The White Wire: Neutral (Usually)

White is the grounded conductor, commonly called the neutral. It returns current from the load back to the service panel. White is never supposed to carry voltage relative to ground in a healthy circuit, but if neutrals are damaged or wired incorrectly, they can become energized.

There is one major exception. In older Romex with switch loops, white wires at the switch end get re-marked with black tape to indicate they are being used as hot. This is code-legal when labeled, and it is one of the most common sources of DIY confusion.

The Green or Bare Wire: Equipment Ground

Green or bare copper is the equipment grounding conductor. It connects metal chassis of fixtures and appliances back to the service panel ground, providing a fault-current path that trips breakers when something goes wrong. Under normal operation, ground wires carry zero current.

The ground wire is the safety net. When a hot wire fails to the metal body of a dryer, the ground wire carries the fault current to the panel, the breaker trips, and nobody gets electrocuted. Disconnecting or skipping grounds is one of the most dangerous DIY shortcuts.

Blue, Yellow, and Orange: Multi-Circuit Applications

In residential construction, blue and yellow appear most often as the third and fourth hots in three-way or four-way switch runs pulled with 4-conductor cable. Orange shows up less often but is standard in 480Y/277V commercial systems as one of the phase legs.

You will rarely encounter blue, yellow, or orange in a typical single-family home outside of multi-way switch installations or commercial-style remodels.

The NEC Three-Phase Color Code

Commercial and industrial wiring uses more colors because 3-phase power requires marking three separate hots.

• 208Y/120V — Black (A), Red (B), Blue (C), White (neutral), Green (ground)
• 480Y/277V — Brown (A), Orange (B), Yellow (C), Gray (neutral), Green (ground)

On 480V systems, gray replaces white as the neutral color. Mixing 480V gray with 120V white wires in the same enclosure is a code violation.

Old Wiring Colors You May Encounter

Houses wired before the 1970s often have color schemes that do not match current code. Knob-and-tube wiring used black and white but had no separate ground. Early Romex sometimes used only black and white without a ground. Some 1960s installations used white for hot instead of neutral — a practice now illegal but still present in many older homes.

If you open a box in an older home and find only two black wires, or a black and white pair with white on a hot terminal, call a qualified electrician. Rewiring older legacy systems to modern standards is not DIY work.

Reading a Typical Outlet Box

A standard modern 15-amp or 20-amp outlet has brass terminal screws (hot), silver terminal screws (neutral), and a green ground screw. In a properly wired box:

1. Black wire → brass screw
2. White wire → silver screw
3. Bare or green wire → green screw
4. Second black and second white (if mid-circuit) land on the unused brass and silver screws

Any deviation — white on a brass screw without marking, black on a silver screw, no ground connection — is a wiring error that needs correction before the box is closed up.

Low-Voltage and Specialty Colors

Color codes for low-voltage wiring are separate from NEC line-voltage codes. Thermostat wiring typically uses red (R), white (W), yellow (Y), green (G), blue (C), and other colors for specific terminals. Doorbell wiring is usually red and white at 16 to 24V. Structured-wiring Cat6 data cables follow TIA/EIA-568 color codes for blue, orange, green, and brown pair pattern.

Never mix low-voltage and line-voltage wires in the same enclosure unless they are separated by a barrier. It is a code violation and a fire hazard.

Re-Marking Conductors

Code allows you to re-mark certain conductors. White used as a hot in a switch loop must be marked with black or red tape or phase tape at every accessible point. Neutral wires 6 AWG and larger can be re-marked with white tape instead of using white-insulated wire. Ground conductors 6 AWG and larger can be re-marked with green tape.

Re-marking must happen at every point the conductor is accessible — both ends and at any junction box along the run.

Final Thoughts

A wire color chart is the first document to memorize before touching anything electrical. Black and red are hot. White is neutral. Bare and green are ground. Commercial and three-phase systems add colors for additional phases. Older homes may have non-standard wiring that deserves a professional eye. Verify every wire with a non-contact voltage tester before you touch it, and respect the code — it exists because people have died learning these lessons the hard way.
