Cattle Panel Chicken Run: Hoop House Build Guide

A cattle panel chicken run is one of the fastest sturdy enclosures you can build in a weekend, because the panels do most of the structural work for you. Bend a 16 foot welded wire panel into an arch, pin both ends to the ground, and you get a rigid hoop that sheds snow, resists wind and gives you enough headroom to walk inside. Line up three to five of those hoops and you have a run 12 to 20 feet long with almost no lumber.

The hoop shape is why so many people call this design a chicken hoop house. It is simple, but a few details decide whether it lasts one season or ten: how far apart you set the base, how you anchor the panel ends, what mesh you add over the large openings, and how you frame the door. Get those right and the run will outlast most wooden pens.

Plan on one long day for two people, plus a second afternoon for mesh and a cover. The most common beginner mistake is setting the base too wide, which flattens the arch and leaves you ducking every time you gather eggs.

Planning a Cattle Panel Chicken Run Layout

Standard cattle panels are 16 feet long and about 50 to 52 inches tall, made from heavy galvanized wire (commonly 4 gauge) with openings around 6 by 8 inches. When you arch a panel, the distance between its two feet sets both the width of the run and its peak height. A few rough numbers help:

• Base 8 feet wide: peak height lands near 6 to 6.5 feet, comfortable for most adults to walk upright down the center.
• Base 7 feet wide: taller and narrower, closer to 6.5 to 7 feet at the peak, with steeper sides that shed snow well.
• Base 10 feet wide: much flatter arch, often under 5 feet tall, and more prone to sagging under a wet tarp.

Length comes from how many panels you set side by side. Each panel covers a little over 4 feet, so four panels give roughly 16 to 17 feet if you butt them, or a bit less if you overlap them by one grid square for extra stiffness. Overlapping is worth it: the joint becomes a double layer of wire that you can clamp tight.

Pick level, well-drained ground. A slope of a few inches over the length is fine, but a run built in a low spot will turn to mud every spring. Keep the long side facing the prevailing wind if you plan to tarp only one end, and leave at least 3 feet of clear space around the outside so you can mow and inspect the skirt. Check any HOA rules and local setback requirements for accessory structures before you buy materials, and call 811 before driving posts if you are anywhere near buried utility lines.

Tools and Materials

You do not need much. Most of the list is fasteners and mesh.

• Cattle panels, one per 4 feet of run length, plus one if you want a closed back wall
• Steel T-posts, 5 or 6 feet long, two per panel end (four per panel) or one per panel foot on smaller builds
• T-post driver, post puller for mistakes, and a tape measure and string line
• Galvanized hog rings and hog ring pliers, or heavy zip ties plus wire for backup
• Half-inch hardware cloth for the lower 3 feet and the ground skirt
• Poultry netting or lighter welded wire for the upper hoop if you want a fully enclosed top
• Pressure-treated 2x4s for the door frame and an optional base rail
• Heavy-duty tarp or corrugated roofing panels for weather cover
• Bolt cutters, heavy leather gloves and eye protection

Budget varies with region and panel prices, but a basic 16 foot hoop run with four panels, T-posts, hardware cloth and a tarp typically lands in the low hundreds of dollars to around $500 to $700 once you add a framed door and quality mesh. Hardware cloth is often the single largest line item, so measure carefully before you buy.

Step-by-Step Hoop Build

1. Mark the footprint. Stake out two parallel lines at your chosen base width, for example 8 feet apart, and run a string along each. Measure the diagonals of the rectangle: when they match, your corners are square.
2. Drive the T-posts. Set posts along each string line, spaced so that each panel edge lands against a post. Drive them 18 to 24 inches deep with the studded face toward the inside of the run so the panel wire can hook behind the studs.
3. Arch the first panel. With one person at each end, set one panel foot inside the posts on one side, then walk the other end toward the opposite line until the panel bows into an arch. Wear gloves: a panel under tension can spring back hard if someone lets go.
4. Lock the feet. Push each end down against the ground inside the posts and wire or clip it to both T-posts at two heights. Galvanized fence clips made for T-posts work well here.
5. Add the remaining panels. Repeat, overlapping each new panel by one grid square over the previous one. Join the overlap every 12 inches or so with hog rings from the ground on one side, over the top and down the other.
6. Check the shape. Sight down the length of the run. If one hoop is taller or leaning, loosen its clips, adjust the base, and re-clip before you add mesh.
7. Frame the ends. Cut a panel to fit the back arch, or build a simple 2×4 frame and skin it with hardware cloth. Frame the front for the door.

Some builders add a pressure-treated 2×4 or 2×6 rail along each base line and staple the panel feet to it. The rail gives the mesh skirt something solid to attach to and keeps the hoop from creeping outward, which matters most on soft soil.

Mesh, Skirts and Predator Proofing

Cattle panel openings are far too large to keep anything out on their own. Treat the panels as the skeleton and the mesh as the actual enclosure.

Wrap half-inch hardware cloth around the lower 3 feet of the hoop on both sides and across both ends. That height covers the zone where digging and reaching animals do most of their damage. Fasten it to the panel every 6 to 8 inches with hog rings or galvanized wire, pulling it snug so there are no loose flaps.

At ground level, add an apron. Lay a strip of hardware cloth 18 to 24 inches wide flat on the ground outward from the base, attach its inner edge to the bottom of the wall mesh, and pin it down with landscape staples. Cover it with soil, gravel or sod. A digging animal hits the wire and gives up instead of tunneling under the edge. Burying the mesh vertically 12 inches deep also works, but it is slower to install.

Above the hardware cloth, lighter poultry netting or 1 by 2 inch welded wire over the top of the hoop keeps climbing and flying predators out. Overlap every seam by at least a few inches and ring it closed. Gaps where mesh meets the door frame are the most common weak point, so double-check every corner with your hand.

Covers: Tarps, Roofing Panels and Shade

Your cover choice depends on climate. The arch shape makes almost any cover easy to fit.

• Heavy tarp: the cheapest option. Pull it over the top third to half of the hoop and tie it to the panel grid with bungee balls or short lengths of rope. Replace it every season or two as UV breaks it down.
• Corrugated polycarbonate or metal panels: more expensive but long-lasting. Screw or wire them to wood purlins clamped across the hoops. Clear panels let light through for winter.
• Shade cloth: ideal for hot summers. Use it alone in warm months and swap in a tarp for winter.

In snow country, cover only the top half so heavy snow can slide off the sides, and brush the cover after storms. A full wet tarp can collect hundreds of pounds of load. In windy areas, leave one end partly open or use mesh-style shade cloth so the run does not act like a sail.

Building a Framed Door

A sagging, gapping door ruins an otherwise tight run. Build a rectangular 2×4 frame at the front end about 30 to 36 inches wide and 5 to 6 feet tall, set it on the ground or on the base rail, and screw two short 2×4 posts to it so it stands on its own. Cut the front panel with bolt cutters to fit around this frame and ring the cut edge to the lumber with fence staples. File or cap cut wire ends so they do not snag skin or clothing.

Hang the door on heavy strap or T-hinges, and use a two-step latch such as a spring bolt plus a hook or a carabiner through a hasp. Clever raccoons can open a simple slide bolt. Leave no more than half an inch between the door and frame, and add a strip of hardware cloth over the bottom rail gap.

Attaching the Run to a Coop

Many owners butt the open end of a cattle panel chicken run directly against an existing coop. Line the hoop up with the pop door, build a 2×4 frame that fits the coop wall, and close the curved gap between the arch and the wall with a custom-cut piece of hardware cloth. Screw the frame to the coop wall studs, not just siding, so the joint does not work loose when wind pushes on the hoop.

If the coop sits on skids or legs, extend the ground apron under and around the coop footprint so there is no gap where the two structures meet.

Troubleshooting Common Problems

• Hoop is lower than expected: the base is too wide. Pull the posts on one side and move them in 6 to 12 inches.
• Panel ends pop off the posts: add a second clip higher up, or a pressure-treated base rail.
• Arch sags in the middle: run a 2×4 ridge purlin down the peak and wire it to each hoop, or add a center post.
• Tarp flaps and tears: tie it every 2 feet and add a second layer of ties at the edges.
• Mud inside the run: add a few inches of coarse wood chips or sand and regrade the outside so water drains away.
• Rust on cut ends: dab cold galvanizing spray on every cut.

When to Call a Pro

Most hoop runs are pure DIY. It is worth hiring help if your site needs significant grading or drainage work, if you want to attach a large run to a permanent structure that may need a permit, or if you plan electrical service for lighting or water heating inside the run. Any new outdoor outlet or circuit should be installed by a licensed electrician with GFCI protection. A fence or landscape contractor can also set posts in rocky ground far faster than hand driving.
