Tile Lippage: Allowable Limits and How to Fix Uneven Edges

Run your bare foot across a new tile floor and feel an edge catch, and you have found the problem nobody notices until the grout is dry. Tile lippage is the height difference between the edges of two neighboring tiles, and a small amount is normal on almost every installation. The question is how much is acceptable, what caused the excess, and whether the fix is worth the disruption. In most homes, a lip you can see under side lighting but cannot feel with a sock is within normal tolerance, while an edge that snags a fingernail or a toe usually is not.

Part of our Tile & Grout guide — explore the full guide →

Industry installation standards set allowable lippage based on grout joint width and the tile’s own flatness. Narrow joints allow less difference because the eye and foot pick up a step more easily when tiles sit tight together. Wide joints, especially with handmade or rustic tile, allow more. Once tile is set and grouted, your options narrow to three: pull and re-set the worst tiles, grind the high edges (only on certain materials), or accept the variation and manage how it looks.

What Tile Lippage Is and How Much Is Allowed

Lippage is measured at the shared edge of two adjacent tiles, not across the whole floor. A floor can be flat overall and still have lipped edges, and a floor can dip gently over 10 feet with zero lippage. Inspectors and installers check it with a straightedge or a small lippage gauge and a set of feeler shims, laying the straightedge across the joint and measuring the gap under the low side.

Commonly cited residential tolerances look roughly like this:

Notice the phrase “plus the tile’s own warpage.” Manufacturers publish a warpage allowance for each tile, and that built-in bow is added to the allowable figure. A large porcelain plank that is slightly crowned in the center will always show some lip at its ends, even when the installer did everything right. That is why a perfectly set floor of long planks can still look uneven when the afternoon sun rakes across it.

Measured lippage versus visible lippage

Two floors with identical numbers can look completely different. Polished and glossy surfaces exaggerate every step because they reflect light along the edge. Matte and textured finishes hide small differences. Low-angle light from a sliding door, a long hallway window or a wall sconce also makes small lips cast shadows. Before you decide a floor is defective, check it with a straightedge rather than judging by eye at sunset.

Why Large-Format and Wall Tile Lip

Lippage almost always comes from one of five sources. Knowing which one caused your problem tells you whether the fix is local or whether the whole surface is suspect.

• Tile bow (warpage). Large porcelain tiles, especially rectangles 24 inches or longer, are rarely perfectly flat. Most have a slight crown or dish in the middle. When the long sides meet at the center of the neighboring tile, as in a 50 percent offset pattern, the high center of one sits next to the low end of another.
• Poor back-buttering and coverage. Large tiles need mortar on both the substrate and the back of the tile so the ridges collapse fully. Skipping the back-butter leaves voids, and tiles settle unevenly as the mortar cures.
• Uneven substrate. A floor or wall that is out of plane by more than the tile can bridge forces the installer to build up mortar in some spots, which invites settling and edge differences.
• Wrong trowel or thin mortar. A notch too small for the tile size leaves too little material to adjust height, and a mortar not rated for large and heavy tile will slump.
• Raking light. Light skimming the surface makes acceptable lippage look worse than it is.

Lippage on wall tile

Uneven edges on wall tile are common in showers and kitchen backsplashes for a few specific reasons. Studs and old drywall are seldom perfectly flat, and walls lose their plane around corners, niches and window returns. Gravity pulls wet tiles down and slightly away from the wall, so the bottom edge of a tile can sit proud of the one beneath it. Subway tile and other elongated shapes with a handmade edge also vary in thickness by design. On walls, the vanity light or a window beside the shower is often the raking light that makes every lip obvious after the job is done.

For a large-format layout, a 1/3 offset instead of a 50 percent offset reduces the effect of tile bow. Most porcelain makers recommend it for planks longer than 18 inches.

How to Check Lippage on an Existing Floor or Wall

You can document the problem yourself in about 20 minutes before calling the installer or deciding on a repair.

1. Clean the surface so grit does not hold the straightedge up.
2. Lay a 12 to 24 inch metal straightedge across a grout joint, centered on the joint.
3. Slide feeler shims or a lippage gauge under the low tile edge. Note the thickest shim that fits.
4. Check several joints in each area: doorways, the center of the room and the zone that catches light.
5. Photograph each reading with the shim in place and mark the tile on a simple sketch of the room.
6. Check the tile carton for the published warpage allowance so you can compare honestly.

If only a handful of joints exceed the tolerance, you have a local repair. If most of the floor is out, the cause is usually substrate preparation or method, and spot repairs will chase the problem around the room.

Repair Options for Tile Already Set

Once mortar has cured, nothing pushes a tile back down. Every fix involves removing material, removing tile or changing how you look at the floor.

Option 1: Remove and re-set individual tiles

This is the cleanest fix when a few tiles are high or low and you have spares from the same lot. The process takes patience but suits a careful DIYer.

1. Cut out the grout around the problem tile with an oscillating tool and a grout blade, working gently along the joint.
2. Score an X across the tile with a carbide scribe if you do not need to save it, then break it out from the center using a cold chisel and a small hammer, working toward the edges so you do not chip neighbors.
3. Scrape the old mortar off the substrate until it is flat. Lower than the surrounding bed is fine; higher is not.
4. Back-butter the new tile with a flat trowel, comb fresh mortar onto the floor with the correct notch, and set the tile with a slight sliding motion to collapse the ridges.
5. Check it against neighbors with a straightedge and tap it down with a rubber mallet. Lift it once and look at the back to confirm near full coverage.
6. Let the mortar cure per the bag (often 24 hours) before grouting.

Keep spare tiles from every job for exactly this reason. Matching a discontinued color later is often impossible.

Option 2: Grind or hone the high edges

Grinding works well on natural stone such as marble, travertine and limestone, which are meant to be honed and polished in place. Professional stone restorers can grind an entire floor flat, then hone and polish it back to a uniform finish. The results can be dramatic, with the floor reading as one continuous surface.

Grinding is a poor choice for most glazed ceramic and glazed porcelain. The color sits in a thin glaze on top, and grinding through it exposes a different colored body underneath. Through-body (color-body) porcelain can sometimes be eased at the edge with a fine diamond pad, but the cut edge will look different from the factory surface. Treat any grinding of man-made tile as a small test on a spare piece first.

Option 3: Live with it and manage the look

Mild excess lippage that does not create a trip edge is often best left alone. Switching a polished floor to a matte sealer or finish on stone, changing a window treatment to soften low-angle light, or placing a runner in a sunlit hall can make the problem nearly disappear. On walls, a diffused vanity fixture mounted over the mirror throws less raking light across the tile than side sconces.

Preventing Lippage on the Next Job

If you are re-tiling a room or planning the next project, prevention costs far less than repair. A tile leveling system is the most effective single tool: reusable or disposable clips slide under adjacent tiles, and caps or wedges pull the edges into the same plane while the mortar cures. They do not fix a bad substrate or poor coverage, but they control the edge differences that come from tile bow and handling.

• Flatten the substrate first. Large tile typically needs a flatter floor than small tile, often no more than 1/8 inch variation in 10 feet.
• Use a large-and-heavy-tile mortar and a notch big enough for full coverage, often 1/2 inch square or larger for big porcelain.
• Back-butter every tile over 15 inches on any side.
• Choose a 1/3 offset for long planks and confirm the tile maker’s layout recommendation.
• Work in smaller sections so mortar does not skin over before tiles go down.

Dust and Safety When Grinding or Cutting Tile

Any removal, cutting or grinding of tile, grout and mortar releases crystalline silica dust, which damages the lungs with repeated exposure. Protect yourself every time:

• Cut and grind wet whenever the tool allows. Wet saws and water-fed grinders keep most dust out of the air.
• Wear a fitted N95 at minimum, and a half-mask respirator with P100 filters for grinding or removing more than a few tiles.
• Wear safety glasses and hearing protection; tile chips fly hard when you break out a tile.
• Isolate the room with plastic sheeting and close HVAC returns while you work.
• Clean up with a HEPA-filtered vacuum and damp wiping. Never dry sweep or use compressed air on tile dust.

If the home was built before the 1980s and you need to scrape down to an older layer, test old flooring or adhesive for asbestos before disturbing it.

Troubleshooting Common Lippage Situations

Lips only at the ends of long planks. Classic tile bow in a 50 percent offset. Spot re-setting rarely helps because the next tile will bow the same way. Manage the light or accept it if it measures within tolerance plus warpage.

One tile rocks or sounds hollow when tapped. The mortar never bonded fully. That tile is likely to crack and should be removed and re-set.

A whole row steps up at a doorway. Usually a substrate change, such as a plywood patch next to the original subfloor. A transition strip may be the practical answer, or the row can be pulled and the substrate corrected.

New grout cracked along a lipped edge. Movement under the tile. Check for hollow spots before regrouting, or the crack will return.

What Repairs Cost and When to Call a Pro

Costs vary widely by region and tile type, so treat these as general ranges. Removing and re-setting a few tiles often runs a few hundred dollars for a tile setter’s service call, more if the tile is large format or requires matching grout across a wide area. Stone grinding, honing and polishing is priced per square foot and usually lands in the low to mid single digits per square foot for an average floor, higher for heavily lipped or small rooms. Full removal and reinstallation, when the substrate is the root cause, can approach the cost of the original job.

Call a professional tile setter or stone restoration specialist when more than a few tiles exceed tolerance, when tiles sound hollow across large areas, when a shower wall is involved (cutting into a waterproofed wall can compromise the membrane), or when you suspect the subfloor is deflecting. If the installation is recent, document your measurements and contact the original installer first, since many contractors stand behind their work for a set period.
