Window Stop Molding: Remove and Replace Without Damage

That thin strip of wood holding the lower sash of a double-hung window in place is the key to almost every window repair. Window stop molding forms the inside channel the sash slides in, and it has to come off before you can free a painted-shut window, replace a sash cord or pull a sash for restoration. Pried off carelessly, it splits and takes paint and casing with it.

Part of our Windows & Doors guide — explore the full guide →

The fix is a patient, methodical removal: score every paint line, work a stiff putty knife in, then lever the stop out gradually with the fastener points pushed through rather than pulled. Reinstalling is just as simple once you leave a small clearance so the sash glides without rattling. Most stops can be reused. If not, new stock in a matching profile is inexpensive.

Here is the full process, from scoring paint to final nailing.

What Window Stop Molding Does

On a typical double-hung window, three pieces of trim work together. The casing frames the window on the wall. The stop, sometimes called window stop trim or the inside stop, runs vertically along both side jambs and across the head, forming the room side of the lower sash channel. Between the two sashes sits the parting bead, a narrow strip set in a groove that separates the upper and lower sash.

Stops are usually 3/8 to 1/2 inch thick and about 1 1/4 to 1 3/4 inches wide, with a rounded, beveled or ogee edge facing the room. Most are held by small finish nails or brads, and in some older homes by screws, so they can be adjusted. Stops differ from casing, which covers the gap between jamb and wall, and from the stop on a door jamb, though the removal technique is similar.

Tools and Materials

• Utility knife with fresh blades, or a paint-scoring tool
• Stiff 1 1/2 inch putty knife and a 2 inch flexible scraper
• Small flat pry bar or trim puller
• Thin wood shims or a scrap block to protect the jamb
• End nippers or locking pliers to pull nails through the back
• Pin nailer or brad nailer (23 gauge pins or 18 gauge brads), or hammer and nail set
• Replacement stop molding if needed, miter saw or miter box, coping saw
• Wood filler, sandpaper, caulk, primer and paint
• Painter’s tape and a pencil to label pieces

Step 1: Score Every Paint Line

Paint bridges the stop to the casing, the jamb and the sash. Run a sharp utility knife along both edges of each stop, cutting through the paint film in several light passes. Also score the line where the sash meets the stop. A dull blade drags and tears paint, so snap off segments often.

On windows painted many times, a paint-scoring tool or a heat gun on low can help, but heat creates its own risks on old paint; read the safety section first.

Step 2: Pry Off the Stop Without Splitting It

Begin at the center of the long side stop, not the end, where the molding flexes most and is least likely to crack.

1. Tap a stiff putty knife into the scored joint between the stop and the jamb.
2. Slide a second putty knife in beside it, then insert the flat pry bar between the two blades so the bar never touches bare wood.
3. Lever gently, just enough to open a 1/8 inch gap. Move 6 to 8 inches along and repeat.
4. Work back and forth along the full length, opening the gap a little more each pass, until the stop pops free.
5. Remove the head stop last, since side stops often overlap or butt into it.

If the stop is screwed in, look for filled screw holes and back them out first. Label each piece (left, right, head) with tape so it goes back in the same place.

Pull the nails out through the back of the stop with end nippers rather than driving them back out the face. That avoids blowing out the painted front.

Step 3: Free a Stuck Sash or Remove It

With one side stop off, a painted-shut lower sash often moves right away. If not, score the joint between the sash and parting bead and work a putty knife around all edges. Tap a scrap block along the sash with a hammer to break remaining paint bonds rather than forcing it.

To remove the lower sash completely, tilt it out of the frame on the side where the stop is removed. On weighted windows, pull the knotted sash cord out of the groove in the sash edge, tie a knot or clamp the cord so the weight does not fall into the pocket, and repeat on the other side. Newer jamb-liner windows typically need the liner compressed or a balance released; follow the sash release method for that style.

To remove the upper sash, pull out the parting bead, which sits tight in its groove and often needs pliers padded with a rag. Parting beads break easily, and replacements are inexpensive.

Step 4: Repair or Choose a New Profile

Inspect each stop. Small splits can be glued and clamped. Scrape paint buildup off the back and the sash-facing edge, since thick paint is often why the window bound in the first place.

If a stop is cracked, rotted or missing, buy new stock at a home center or lumberyard. Common profiles include:

• Bullnose or rounded stop: Simple, common on mid-century and newer homes.
• Ogee stop: A traditional curved profile found on older houses.
• Square or beveled stop: Clean and modern; easy to match when the original cannot be found.

Take a short offcut to the store to match thickness, width and edge shape. If nothing matches, a millwork shop can run a custom profile, or you can replace all stops on the window with a new profile so they match each other. Primed finger-jointed pine is inexpensive and paints well; solid pine or poplar is better for stained trim.

Cut new side stops to length with square ends or a cope where they meet the head stop, depending on how the originals joined. Copy the old pieces exactly for best results.

Step 5: Reinstall and Re-Nail the Stops

Clean old paint and nails out of the jamb, reinstall the sashes and parting bead, and reconnect sash cords if your window uses weights.

1. Set the head stop first, then the side stops.
2. Hold each stop against the sash, then back it off about 1/32 inch. A business card or thin cardboard strip makes a good spacer. Too tight and the sash binds; too loose and it rattles and leaks air.
3. Fasten every 8 to 12 inches with 1 1/4 inch pins or brads, angling slightly into the jamb.
4. Slide the sash up and down. If it drags, tap the stop slightly outward before the fasteners are set; a pin nailer leaves tiny holes, which makes adjustments easy.

A pin nailer is the ideal tool here. The thin 23 gauge pins rarely split narrow molding and leave holes small enough to vanish under a dab of filler. Use brads if the stop needs more holding power.

Step 6: Finish and Paint

Fill nail holes, sand lightly, and caulk only the joint between stop and casing. Never caulk the sash side, or the window will be stuck again. When painting, keep paint off the sash edges and the face of the stop that rubs the sash; run the window up and down several times as the paint dries so nothing bonds. A light rub of paraffin wax in the channel helps the sash glide.

Troubleshooting

Stop splits as you pry: Stop, score the paint again and start from the middle. Glue the split and clamp it.

Sash still binds after reinstalling: Check for paint ridges in the channel, a warped stop or a swollen sash. Plane only the sash edge, a little at a time.

Window rattles or drafts: Stops are too far from the sash. Move them in slightly, or add a small weatherstrip rated for sliding windows.

Costs

Replacement stop molding usually costs a few dollars per linear foot, so a typical window needs well under $25 in material. A pin nailer is a moderate tool purchase that pays off on any trim work. A carpenter or window restoration pro typically charges $75 to $250 per window to free and re-stop sashes, more if cords, glazing or rot repair are involved.

Lead Paint Safety and When to Call a Pro

Many homes built before 1978 have lead paint on window trim, and friction surfaces such as stops and sashes are where lead dust collects. Test the paint with a lead test kit or a certified inspector before scoring, prying or sanding. If lead is present, use lead-safe practices: plastic sheeting below the work area, mist surfaces before scraping, avoid dry sanding and open-flame or high-heat stripping, wear a P100 respirator, and clean up with a HEPA vacuum and wet wiping. Keep children and pets away from the work area. On very old homes, glazing putty and caulk can also contain asbestos; have suspect material tested before disturbing it.

Hire a lead-safe certified contractor for extensive lead paint work, and a window restoration specialist when sashes are rotted, glass is cracked or weighted windows need rebuilding.
