Deck Beam Spacing: How Far Apart Beams Go for Joist Spans

The most common deck framing mistake is not an undersized beam, it is a beam placed too far from the ledger or the next beam. Deck beam spacing is controlled almost entirely by joist span: the distance between beams (or between a ledger and a beam) can never exceed what your joists are allowed to span at their size, species and on-center spacing. For typical pressure-treated southern pine joists at 16 inches on center, that works out to roughly 9 feet for 2×6, 12 feet for 2×8, 15 feet for 2×10 and 18 feet for 2×12.

Part of our Decks & Outdoor guide — explore the full guide →

Once you know the joist span, beam placement falls into place. An attached 12-foot-deep deck with 2×8 joists can usually get away with one beam near the outer edge. A 16-foot-deep deck with the same joists needs either deeper joists or a second beam. Post spacing along each beam is a separate question that depends on beam size, and it interacts with beam spacing because a beam carrying longer joists carries more load.

How Deck Beam Spacing Is Determined

Think of a deck frame as layers. Decking sits on joists. Joists sit on a ledger at the house and on one or more beams. Beams sit on posts, and posts sit on footings. Each layer spans between supports from the layer beneath it.

The span of each joist runs from the face of the ledger to the center of the beam, or from beam to beam on a freestanding deck. That span is the beam spacing. So the question “how far apart should beams be” really means “how far can these joists span.” Look that number up in the span table your local building department uses, which reflects lumber species, grade, size, on-center spacing and design loads.

Typical Joist Spans That Set Beam Distance

The figures here are typical examples for pressure-treated southern pine, No. 2 grade, at common residential deck loads (40 pounds per square foot live load plus 10 dead load). Other species such as hem-fir or Douglas fir are often a little shorter. Local tables and snow loads govern.

Composite and PVC decking often requires joists at 12 or 16 inches on center, and diagonal decking usually requires 12 inches. Tighter joist spacing increases allowable span a little, but it also adds joists and cost.

Beam Spacing for Common Deck Sizes

Attached decks

On a deck fastened to the house with a ledger, the ledger acts as the first support. If the deck projects 10 feet from the house, 2×8 joists at 16 inches can reach a single beam set about 10 feet out, or set back a little with a short cantilever. A 14-foot-deep attached deck typically uses 2×10 joists to reach one beam, or 2×8 joists with a mid-deck beam.

Freestanding decks

A freestanding deck has no ledger, so it needs at least two beams. A 12 by 12 freestanding deck with 2×8 joists might use beams about 10 to 11 feet apart with short cantilevers on each side. A 16-foot-deep freestanding deck with 2×8 joists usually needs three beams, or two beams with 2×10 or 2×12 joists.

Using cantilevers

Joists can extend past the beam as a cantilever, which tucks the beam and posts under the deck and lets you set beams closer than the full deck depth. A common prescriptive limit is a cantilever of no more than one quarter of the backspan (the joist span behind the beam). With a 12-foot backspan, that allows about 3 feet of overhang. Many local guides add a fixed maximum as well, and stiffer decking or heavy railing loads can lower it.

Post Spacing Along the Beam

Beam spacing and post spacing are linked. A beam supporting 12-foot joists carries more load than one supporting 8-foot joists, so it needs posts closer together or a deeper beam. Typical examples for a built-up beam of pressure-treated southern pine:

• Doubled 2×8 beam with joists spanning about 8 feet: posts roughly 7 to 8 feet apart
• Doubled 2×10 beam with joists spanning about 10 to 12 feet: posts roughly 6 to 8 feet apart
• Tripled 2×12 beam with joists spanning about 12 feet: posts roughly 9 to 10 feet apart

The trade-off is simple: a bigger beam lets you use fewer posts and footings, while a smaller beam is lighter to lift but needs more holes. Many builders choose beam size first to keep footing count reasonable, then confirm against the local beam span table.

Tools and Materials

• Pressure-treated joist and beam lumber, ground-contact rated where required
• Posts, typically 6×6 for elevated decks
• Post bases, post-to-beam connectors, joist hangers and hurricane ties rated for treated lumber
• Circular saw for cutting joists and beam plies
• Tape measure, string line, framing square and 4-foot level
• Post hole digger or auger, concrete and footing forms
• Exterior structural screws, through-bolts and galvanized nails

A good circular saw does most of the work. A 7-1/4-inch blade cuts through a 2×12 in one pass, and a speed square guides square cuts on joists and beam plies.

Step by Step: Laying Out Beam Locations

1. Set deck size and decking. Decide overall depth and width, decking material and joist on-center spacing, since decking dictates joist spacing.
2. Choose joist size. Pick the joist size that can span the depth with one beam if possible, using your local span table.
3. Locate the beam. Measure the allowable joist span out from the ledger face. Place the beam at or inside that line. Decide whether to cantilever joists past it.
4. Size the beam and posts. Using the actual joist span, look up beam size and allowable post spacing.
5. Lay out footings. Run string lines, square the layout using the 3-4-5 method, and mark post centers.
6. Call 811 and dig. Have utilities marked before you dig. Dig footings to the size and frost depth your local code requires.
7. Set posts and beam. Install posts, cut them level, and fasten the beam with approved post-to-beam connectors, not just toe nails.
8. Hang joists. Set joists in hangers at the ledger and fasten them to the beam with ties, then add blocking and rim joists.

Troubleshooting Spacing Problems

The deck feels bouncy in the middle

Joists may be at or past their span limit. Adding a mid-span beam shortens the span and stiffens the floor. Sistering larger joists is another option.

The beam sags between posts

Post spacing is too wide for the beam size and load. Add a post and footing, or replace the beam with a deeper or additional ply.

Footings landed on a buried line or in a bad spot

Shift beam location within the allowable span, or add a cantilever to move posts inward. Never notch a beam to fix layout errors.

Inspector flagged the beam cantilever

Beams usually can overhang posts only a limited amount, often around one quarter of the beam span between posts. Excessive overhang needs another post.

Structural Safety

Deck framing carries people, furniture and snow over open air, so treat it as structural work. Anchor posts to footings with approved connectors, set footings below frost depth on undisturbed soil, attach ledgers to the house rim with approved fasteners and flashing, and design for the snow and wind loads in your area. Call 811 at least a few days before digging. Most jurisdictions require permits and inspections for decks, and HOAs may restrict size and height. Hot tubs and roof-covered decks need an engineered design.

Costs and When to Call a Pro

Each footing typically adds a modest amount in concrete, hardware and labor, so reducing posts with a larger beam can save money on rocky or hard soil. Larger joists cost more per board but can eliminate a whole beam line. Professional deck framing costs vary widely by region and height, often from a few thousand dollars for small ground-level decks to much more for elevated ones.

Hire a licensed deck builder or engineer for elevated decks, decks on slopes, structures carrying hot tubs, or any design outside your local prescriptive guide. A pro will verify deck beam spacing, beam size and footing design together, which is where most framing failures start.
