A small bathroom doesn’t have to feel cramped. The right floor plan makes all the difference between a functional space and one that frustrates you every morning. This guide covers specific layouts for common small bathroom dimensions, including half baths, three-quarter baths, and full baths ranging from 5×7 to 6×8 feet.
Part of our Bathroom Remodeling & Flooring guide — explore the full guide →
- Understanding Small Bathroom Types
- Clearance Requirements You Need to Know
- 5×7 Bathroom Floor Plans
- 5×8 Bathroom Floor Plans
- 6×8 Bathroom Floor Plans
- Half Bath Floor Plans
- Three-Quarter Bath Floor Plans
- Fixture Placement Principles
- Space-Saving Tips That Actually Work
- Cost to Remodel a Small Bathroom (2026)
- Common Mistakes to Avoid
- Small Bathroom Configurations by Footprint
Understanding Small Bathroom Types
Before choosing a layout, it helps to know what category your bathroom falls into based on its fixtures:
- Half bath (powder room): Toilet and sink only. Minimum size is roughly 3×6 feet (18 square feet), though 4×5 or 5×5 is more comfortable.
- Three-quarter bath: Toilet, sink, and shower (no tub). Works well in spaces as small as 5×6 feet (30 square feet).
- Full bath: Toilet, sink, shower or tub (or a tub/shower combo). Needs at least 5×7 feet (35 square feet) to meet code in most jurisdictions.
Clearance Requirements You Need to Know
Local building codes vary, but the International Residential Code (IRC) sets baseline clearances that most municipalities adopt:
- Toilet center: Minimum 15 inches from the side wall or any obstruction (18 inches is recommended).
- Front clearance: At least 21 inches of clear space in front of the toilet and sink (24 inches preferred).
- Shower interior: Minimum 30×30 inches, though 36×36 is the practical minimum for comfort.
- Door swing: A standard 24-inch door needs about 28 inches of swing clearance. Consider pocket doors or barn doors for tight spaces.
5×7 Bathroom Floor Plans
The 5×7 layout (35 square feet) is one of the most common small full bathrooms in American homes, especially in houses built from the 1950s through 1980s.
Layout A: Standard Tub Along the Back Wall
This is the classic configuration. The 5-foot tub fits perfectly against the 5-foot back wall. The toilet sits along one side wall, and the sink goes on the same wall or the opposite wall near the door.
- Tub/shower combo on the short (5-foot) wall
- Toilet on the long wall, 15 inches from the tub wall
- Pedestal or wall-mounted sink opposite the toilet or next to the door
- Door on the 5-foot wall opposite the tub
This layout keeps plumbing on one or two walls, which saves on installation costs. A standard 30×60-inch alcove tub fits the back wall exactly.
Layout B: Linear Arrangement
All three fixtures line up along one long wall. The tub goes at the far end, the toilet in the middle, and the sink nearest the door. This works when plumbing access is limited to one wall.
Layout C: Corner Shower Instead of Tub
Replacing the tub with a 36×36-inch corner shower opens up significant floor space. You gain room for a larger vanity (up to 36 inches wide) and more comfortable movement around the toilet. This is the best option if no one in the household needs a bathtub.
5×8 Bathroom Floor Plans
At 40 square feet, the 5×8 bathroom gives you an extra 5 square feet over the 5×7. That additional foot of length creates noticeably more breathing room.
Layout A: Tub With Separate Vanity Zone
The extra length lets you create visual separation between the vanity area and the tub/toilet area. Place the tub on the back 5-foot wall, the toilet along one side wall, and a 30- to 36-inch vanity on the opposite side wall closer to the door. You’ll have roughly 24-28 inches of clearance in front of the vanity, which meets code.
Layout B: Walk-In Shower With Bench
A 36×48-inch shower fits along the back wall with room to spare. Add a built-in bench at one end. The toilet and a 30-inch vanity fit comfortably on opposite side walls.
Layout C: Double Entry
In a Jack-and-Jill configuration, doors enter from both 5-foot walls. The tub goes along one long wall, with the toilet and sink on the opposite long wall. This layout requires careful door placement to maintain clearances.
6×8 Bathroom Floor Plans
At 48 square feet, the 6×8 bathroom opens up real possibilities. That extra foot of width compared to a 5×8 makes fixture placement much more flexible.
Layout A: Tub and Separate Shower
Yes, you can fit both in a 6×8. Use a 48-inch soaking tub (shorter than standard) along one wall and a 32×32-inch corner shower on the adjacent wall. The toilet and a 24-inch vanity fit on the remaining walls. It’s tight but functional.
Layout B: Spacious Single-Fixture Wet Area
A 36×60-inch shower or standard tub along the 6-foot wall leaves 6×3 feet of open floor for the toilet and vanity. You can fit a 48-inch vanity in this configuration, which is a significant upgrade for storage.
Layout C: L-Shaped Vanity
Wrap a custom vanity around one corner, giving you counter space along two walls. Pair it with a 36×36-inch shower and a toilet on the opposite wall. This layout maximizes storage and counter space.
Half Bath Floor Plans
Half baths (powder rooms) only need a toilet and sink, so they can fit into surprisingly small spaces.
Minimum Viable: 3×6 Feet (18 sq ft)
The toilet goes at the far end, and a wall-mounted sink or corner sink goes near the door. The door must swing outward or be a pocket door. This is the absolute minimum and feels tight.
Comfortable: 4×6 Feet (24 sq ft)
The extra foot of width makes a noticeable difference. You can use a pedestal sink or a small 18-inch vanity. The door can swing inward if positioned correctly.
Ideal: 5×5 Feet (25 sq ft)
A square half bath gives you options. Place the toilet and sink on adjacent walls or the same wall. There’s room for a 24-inch vanity with storage, a mirror, and comfortable movement.
Three-Quarter Bath Floor Plans
A 3/4 bath includes a toilet, sink, and shower but no tub. These work well as secondary bathrooms, basement baths, or guest baths.
5×6 Feet (30 sq ft)
A 32×32-inch corner shower fits in the back corner. The toilet goes along one side wall, and a 24-inch vanity fits on the opposite wall near the door. Use a clear glass shower door to make the space feel larger.
5×7 Feet (35 sq ft)
At this size, you can upgrade to a 36×36-inch shower with a swinging glass door. A 30-inch vanity fits comfortably, and there’s room for a recessed medicine cabinet and towel bar without crowding the space.
Fixture Placement Principles
Beyond the specific layouts above, these principles apply to any small bathroom floor plan:
Wet Wall Strategy
Keep the toilet, sink, and shower/tub supply lines on as few walls as possible. Every additional wet wall adds $500-$1,500 in plumbing costs (2026 pricing). Ideally, the toilet and sink share one wall, and the tub/shower is on an adjacent wall.
Door Placement
The door location often dictates the entire layout. Consider these options for small bathrooms:
- Pocket door: Saves the most space. Costs $300-$800 installed for a basic model.
- Barn door: Needs clear wall space to slide. Doesn’t seal as tightly as a pocket door. Costs $200-$600 for hardware plus the door.
- 24-inch swing door: The narrowest standard prehung door. Works when outward swing is possible.
Toilet Placement
Place the toilet where it’s least visible from the doorway. In most small bathrooms, this means along the wall adjacent to the door, behind the door swing. Compact elongated toilets (about 28 inches deep instead of 31) save 2-3 inches of clearance.
Sink Options by Size
- Wall-mounted sink: Takes up zero floor space. Exposes plumbing underneath unless you add a shroud ($40-$80).
- Corner sink: Fits a 90-degree corner, freeing up wall space. Typically 15-20 inches wide.
- Pedestal sink: Classic look, small footprint, but no storage. Base is typically 8-10 inches wide.
- 18-inch vanity: The smallest standard vanity. Provides some storage. Available at most home improvement stores for $150-$400.
- 24-inch vanity: A good compromise between storage and space. Prices range from $200-$600.
Space-Saving Tips That Actually Work
Use the Vertical Space
Small bathrooms have the same wall height as large ones. Install shelving above the toilet (an over-toilet cabinet or floating shelves), a tall narrow linen cabinet (12 inches wide fits between many fixtures), and a recessed medicine cabinet (gains 3.5 inches of depth into the wall).
Choose the Right Shower Door
A swinging shower door needs 24-30 inches of clearance to open. A sliding door needs zero clearance. A frameless glass panel (fixed, with an open entry) eliminates the door entirely and makes the room feel bigger. For tub/shower combos, a curved shower rod adds about 6 inches of elbow room inside the tub.
Float Everything Possible
Wall-mounted toilets, floating vanities, and wall-mounted sinks create visible floor space, which makes the room feel larger. A wall-mounted toilet requires a carrier frame inside the wall ($200-$400 for the carrier) but saves 8-10 inches of depth compared to a standard floor-mounted toilet.
Use Large-Format Tile
Counterintuitively, larger tiles (12×24 or larger) make small bathrooms look bigger because there are fewer grout lines to break up the visual space. Diagonal tile patterns also create an illusion of more space.
Light Colors and Good Lighting
White, light gray, and soft beige walls reflect more light and make the room feel open. Add a backlit mirror or LED strip lighting under a floating vanity to eliminate shadows. A single overhead light creates harsh shadows that make a small room feel smaller.
Cost to Remodel a Small Bathroom (2026)
If you’re reconfiguring your small bathroom layout, here’s what to budget:
- Cosmetic refresh (new fixtures, paint, flooring, no layout changes): $3,000-$7,000
- Layout change on existing wet walls: $8,000-$15,000
- Full gut and reconfigure (moving plumbing, new everything): $15,000-$30,000
- Converting a closet or unused space to a half bath: $8,000-$20,000 depending on proximity to existing plumbing
The single biggest cost driver in a small bathroom remodel is moving plumbing. If you can keep the drain locations where they are and just swap fixtures, you’ll save thousands.
Common Mistakes to Avoid
- Ignoring the door swing: A door that hits the toilet or vanity when it opens is a daily frustration. Plan the door first, then place fixtures.
- Choosing fixtures that are too large: A 60-inch double vanity in a 5×7 bathroom leaves no room for anything else. Measure twice.
- Skipping ventilation: Small bathrooms accumulate moisture faster. An exhaust fan rated for at least 50 CFM (1 CFM per square foot) is essential to prevent mold.
- Forgetting about storage: A beautiful minimalist bathroom with nowhere to put towels, toilet paper, or toiletries isn’t functional. Plan storage into the layout from the start.
Small Bathroom Configurations by Footprint
Most small bathroom configurations fall into a handful of repeatable patterns, and the room’s proportions usually decide which one works before style ever enters the picture.
Long and Narrow Rooms
A narrow rectangle favors a linear arrangement: every fixture lines up along one long wall, with the open floor running beside them like a hallway. The door typically sits on a short end or in the middle of the long wall opposite the fixtures. This pattern keeps plumbing on one wall and leaves the walkway clear, though a frameless glass shower panel at the far end keeps it from feeling like a corridor.
Square Rooms
A roughly square room opens up a split arrangement, with the toilet and vanity on one wall and the shower or tub on the adjacent wall. Corner showers suit square rooms well because the angled or neo-angle door frees floor area in front of the other fixtures. Square rooms also tolerate a door swinging inward more easily, since the swing arc lands in open floor rather than on a fixture.
Rooms With a Sloped Ceiling or Odd Wall
Attic baths and rooms under stairs need the tallest activities placed where the ceiling is highest. Put the shower and the standing area in front of the vanity under full height, and tuck the toilet toward the lower side where a seated user needs less headroom. Confirm the local minimum ceiling height over each fixture before committing, since requirements differ by jurisdiction.
Clearances to Confirm Locally
Typical guidance calls for side clearance from the toilet centerline, open floor in front of the toilet and sink, and a minimum interior size for showers. Treat these as starting points only. Your local building department may have adopted amended rules, and accessibility goals push numbers higher. Mark fixture outlines on the floor with painter’s tape and walk through the room, sit on a chair where the toilet goes, and open the door fully to check that nothing collides.
Grouping Fixtures on a Wet Wall
Placing the toilet, sink and shower valve on one shared wet wall shortens supply and drain runs and keeps venting simpler. If the room must use two walls, keep them adjacent so lines can turn the corner rather than crossing the floor. Before moving a toilet even a short distance, check joist direction underneath, because a drain line that has to cut across joists can require structural work. Plumbing changes generally need a permit, and a licensed plumber can confirm slope, venting and drain sizing for your layout.
Choosing Between Tub and Shower
In the smallest footprints, the tub or shower decision drives everything else. A tub fills one short wall neatly in a classic five-foot room, while a shower lets you shrink the wet zone and reclaim floor.
